Conductor
Soft annealed electrolytic copper Cu-ETP according to DIN EN 13602, bare. Conductor construction according to ISO 6722
Insulation
Plasticized PVC with properties according to ISO 6722, Class B, lead free
Standards
ISO 6722
Temperature Rating
-40°C to +105°C
Dimensions
|
Nominal cross sectional area Sq. mm
|
No. of strands
|
Diameter of single wire Max. mm
|
Diameter of conductor Nom. Mm
|
DC Conductor resistance at 20°C Ω/km, Max.
|
Wall thickness mm. Nom.
|
Diameter of core mm
|
Sheath wall thickness mm
|
Overall Diameter
|
|
(Min.)
|
(Max.)
|
|
0.5
|
16
|
0.21
|
1
|
37.1
|
0.6
|
2.1
|
0.4
|
2.7
|
3.1
|
|
0.75
|
24
|
0.21
|
1.2
|
24.7
|
0.6
|
2.3
|
0.4
|
3
|
3.3
|
|
1
|
32
|
0.21
|
1.35
|
18.5
|
0.6
|
2.5
|
0.4
|
3.2
|
3.6
|
|
1.5
|
30
|
0.26
|
1.7
|
12.7
|
0.6
|
2.8
|
0.5
|
3.7
|
4.1
|
|
2
|
40
|
0.26
|
2
|
9.42
|
0.6
|
3
|
0.5
|
3.9
|
4.3
|
|
2.5
|
50
|
0.26
|
2.2
|
7.6
|
0.7
|
3.5
|
0.5
|
4.3
|
4.8
|
