Cable Construction
1.1 kV, 1 cores AL/ CU conductor, XLPE insulated, aluminum strip / wire armoured cables as per IS 7098 Part -1.
Conductor: AL up to 10 Sq. mm conductor are solid Cl. 1 as per IS 8130. And above 10 Sq. mm conductor are stranded round or compact Cl. 2 as per IS 8130
In CU 4 & 6 Sq. mm conductor are solid Cl. 1 or stranded Cl. 2 as per IS 8130. 10 Sq. mm & above stranded round or stranded compact Cl. 2 as per IS 8130
Insulation : Crosslinked polyethylene (XLPE)
Core Color : Red or yellow or blue or black
Armouring : Single armouring of aluminum strip or aluminum wire as per IS 7098 P -1
Outer Sheath : PVC Type ST - 2 as per IS 5831 (Option : FR Type / FRLS Type)
Cable Color: Black (Options : Any other color as per requirement)
Cable Design Parameters
While ordering, in addition to the part number the following details shall also be advised:
Conductor Type (Aluminium or Copper) and class of conductor (Cl. 1 or 2).
Sheath Type - PVC Type ST - 2 (FR or FRLS).
Colour from above technical details.
| Part Number | Nominal Cross – Sectional Area (Sq. mm) | Nominal Thickness of Insulation (mm) | Armouring with flat strip (A2XFaY/2XFaY) | Armouring with Round Wire (AYWaY/yWaY) |
| Nominal thickness of Arm. Strip (mm) | Minimum Thickness of outer Sheath | Approx. Overall Dia. (mm) | Approx. Net Wt. of Cable (kg/km) | Nominal Diameter of Wire (mm) | Minimum Thickness of Outer Sheath (mm) | Approx. Overall Dia. (mm) | Approx. Net Wt. of Cable (kg/km) |
| Al Cable A2XFaY | Cu Cable 2XFaY | AL Cable AYWaY | CU Cable YWaY |
| 111800100016 |
16 |
1.0 |
N/A |
N/A |
N/A |
N/A |
N/A |
1.4 |
1.24 |
13 |
200 |
300 |
| 111800100025 |
25 |
1.2 |
N/A |
N/A |
N/A |
N/A |
N/A |
1.4 |
1.24 |
14 |
300 |
455 |
| 111800100035 |
35 |
1.2
|
N/A |
N/A |
N/A |
N/A |
N/A |
1.4
|
1.24
|
15 |
350 |
567 |
| 111800100050 |
50 |
1.3
|
N/A |
N/A |
N/A |
N/A |
N/A |
1.4
|
1.24
|
17 |
420 |
730 |
| 111800100070 |
70 |
1.4
|
N/A |
N/A |
N/A |
N/A |
N/A |
1.4
|
1.24
|
19 |
520 |
954 |
| 111800100095 |
95 |
1.4
|
0.8
|
1.40
|
21 |
600 |
1195 |
1.6
|
1.4
|
22 |
650 |
1235 |
| 111800100120 |
120 |
1.5
|
0.8
|
1.40
|
23 |
700 |
1450 |
1.6
|
1.4
|
24 |
750 |
1494 |
| 111800100150 |
150 |
1.7
|
0.8
|
1.40
|
24 |
800 |
1730 |
1.6
|
1.4
|
25 |
850 |
1780 |
| 111800100185 |
185
240 |
1.9
|
0.8
|
1.40
|
26 |
950 |
2100 |
1.6
|
1.4
|
28 |
1000 |
2147 |
| 111800100240 |
2.0
|
0.8
|
1.40
|
30 |
1200 |
2690 |
1.6
|
1.4
|
30 |
1250 |
2738 |
| 111800100300 |
300
400 |
2.1
|
0.8
|
1.56
|
32 |
1400 |
3270 |
1.6
|
1.56
|
33 |
1500 |
3360 |
| 111800100400 |
2.4
|
0.8
|
1.56
|
36 |
1750 |
4230 |
2.0
|
1.56
|
38 |
1900 |
4380 |
| 111800100500 |
500 |
2.6
|
0.8
|
1.56
|
39 |
2150 |
5250 |
2.0
|
1.56
|
41 |
2350 |
5450 |
| 111800100630 |
630 |
2.8
|
0.8
|
1.72
|
44 |
2700 |
6610 |
2.0
|
1.72
|
46 |
2900 |
6806 |
| 111800100800 |
800 |
3.1
|
0.8
|
1.72
|
48 |
3350 |
8320 |
2.0
|
1.88
|
51 |
3600 |
8560 |
| 111800101000 |
1000 |
3.3
|
0.8
|
1.88
|
54 |
4100 |
10300 |
2.5
|
2.04
|
56 |
4600 |
10800 |
