Cable Construction
1.1 kV, 3.5 cores AL / CU conductor, XLPE insulated, galvanised steel strip / wire armoured Cables as per IS 7098 Part -1.
Conductor : AL / CU stranded compact shaped conductor as per Cl. 2, IS 8130.
Insulation : Crosslinked polyethylene (XLPE)
Phase Core Color : Red, yellow, blue
Neutral Core Color : Black
Inner Sheath : PVC / PVC tape as per IS 7098 (P - 1)
Armouring : Single armouring of galvanised steel strip / wire
Outer Sheath : PVC Type ST - 2 as per IS 5831. (Option : FR Type / FRLS Type)
Cable Color : Black (Options : Any other color as per requirement)
Cable Design Parameters
While ordering, in addition to the part number the following details shall also be advised:
Conductor Type (Aluminium or Copper) and class of conductor (Cl. 1 or 2).
Sheath Type - PVC Type ST - 2 (FR or FRLS).
Part
Number | Size Cores x Sq. mm + Neutral (Sq. mm) | Nominal
Thickness
of
Insulation
(mm) | Minimum Thickness of Inner Sheath (mm) | | Armouring with flat strip (A2XFY/ 2XFY) | Armouring with round wire (A2XWY/ 2XWY) |
Nominal
Thickness
of Arm. Strip
(mm) | Minimum Thickness of Outer Sheath (mm) | Approx. Overall Dia. (mm) | Approx. Net Wt.
of Cable (kg/km) | Nominal Diameter of Wire (mm) | Minimum Thickness of Outer Sheath (mm) | Approx. Overall Dia. (mm) | Approx. Net Wt.
of Cable (kg/km) |
AL Cable
A2XFY | CU Cable
2XFY | AL Cable
A2XWY | CU Cable 2XWY |
| 112101010211 |
3 x 25 + 16 |
0.9/0.7 |
0.3 |
0.8 |
1.40 |
23 |
900 |
1400 |
1.6 |
1.40 |
25 |
1080 |
1685 |
| 112101020211 |
3 x 35 + 16 |
0.9/0.7 |
0.3 |
0.8 |
1.40 |
25 |
1000 |
1800 |
1.6 |
1.40 |
27 |
1285 |
1980 |
| 112101030211 |
3 x 50 + 25 |
1.0/0.9 |
0.3 |
0.8 |
1.40 |
28 |
1200 |
2300 |
1.6 |
1.56 |
30 |
1580 |
2685 |
| 112101040211 |
3 x 70 + 35 |
1.1/0.9 |
0.4 |
0.8 |
1.56 |
32 |
1600 |
3200 |
2.0 |
1.56 |
35 |
2190 |
3690 |
| 112101050211 |
3 x 95 + 50 |
1.1/1.0 |
0.4 |
0.8 |
1.56 |
35 |
2000 |
4100 |
2.0 |
1.56 |
38 |
2580 |
4585 |
| 112101060211 |
3 x 120 + 70 |
1.2/1.1 |
0.4 |
0.8 |
1.72 |
39 |
2400 |
5100 |
2.0 |
1.72 |
42 |
3085 |
5680 |
| 112101070211 |
3 x 150 + 70 |
1.4/1.1 |
0.5 |
0.8 |
1.72 |
43 |
2800 |
6000 |
2.0 |
1.88 |
46 |
3590 |
6790 |
| 112101080211 |
3 x 185 + 95 |
1.6/1.1 |
0.5 |
0.8 |
1.88 |
47 |
3400 |
7400 |
2.5 |
2.04 |
51 |
4675 |
8615 |
| 112101090211 |
3 x 240 + 120 |
1.7/1.2 |
0.6 |
0.8 |
2.04 |
53 |
4300 |
9500 |
2.5 |
2.20 |
56 |
5680 |
10485 |
| 112101100211 |
3 x 300 + 150 |
1.8/1.4 |
0.6 |
0.8 |
2.20 |
57 |
5000 |
11500 |
2.5 |
2.36 |
60 |
6685 |
12990 |
| 112101110211 |
3 x 400 + 185 |
2.0/1.6 |
0.7 |
0.8 |
2.52 |
66 |
6400 |
14500 |
3.2 |
2.68 |
71 |
8980 |
16980 |
| 112101120211 |
3 x 500 + 240 |
2.2/1.7 |
0.7 |
0.8 |
2.68 |
74 |
7900 |
18000 |
3.2 |
2.84 |
79 |
10985 |
21485 |
| 112101130211 |
3 x 630 + 300 |
2.4/1.8 |
0.7 |
0.8 |
3.00 |
82 |
9900 |
23000 |
4.0 |
3.00 |
88 |
14490 |
27985 |
