PVC double insulated cable, for welding machines. Used to conduct secondary voltage in secondary side connection to MMA welding power sources. Stranded, red copper conductor wire.
Working Voltage U/U
Max. 450 V a.c. r.m.s.
Minimum Bending Radius
5 x cable diameter
Application
The welding cable is specially designed for the transmission of high currents from the electric welding machine to the welding tool. It is suitable for flexible use under rugged conditions, on assembly lines and conveyor systems, in machine tool and motor car manufacturing, shipbuilding, for welding machines.
Cable Construction
Superfine strands of plain copper with double elastometric PVC insulation.
Test Voltage
3000 V
Outdoor Installation
Permanent
Temperature Range
0°C to +70°C
Dimensions
No. of Cores x Nominal
Cross Sectional
Area Sq. mm | Max. Strand
Diameter
(mm) | Max. CR
(Spec)
Ω/km | Nominal
Insulation Thickness
mm | Nominal
Sheath thickness
mm | Nominal
Cable Diameter
mm | Approx
Weight
kg/km |
| 10 |
0.30 |
1.91 |
2.0 |
1.2
1.2 |
10.6 |
180 |
| 16 |
0.30 |
1.21 |
2.0 |
11.7 |
250 |
| 25 |
0.30 |
0.78 |
2.0 |
1.4 |
13.3 |
350 |
| 35 |
0.30 |
0.554 |
2.0 |
1.6 |
14.7 |
460 |
| 50 |
0.30 |
0.386 |
2.2 |
1.8 |
17.2 |
650 |
| 70 |
0.30 |
0.272 |
2.4 |
2.0 |
19.6 |
880 |
| 95 |
0.30 |
0.206 |
2.6 |
2.1 |
22.4 |
1170 |
| 120 |
0.30 |
0.161 |
2.8 |
2.3 |
24.2 |
1430 |
| 150 |
0.30 |
0.129 |
3.0 |
2.4 |
26.1 |
1720 |
