Unarmoured Cable A2XY/2XY 2 Core

RR Kabel

1.1 kV, 2 cores AL/ CU conductor, XLPE insulated, unarmoured cables as per IS 7098 Part -1

Cable Construction

1.1 kV, 2 cores AL/ CU conductor, XLPE insulated, unarmoured cables as per IS 7098 Part -1.
Conductor : AL up to 10 Sq. mm conductor are solid Cl. 1 as per IS 8130. And above 10 Sq. mm conductor are stranded round or compact round or compact shape conductor Cl. 2 as per IS:8130
In CU 4 & 6 Sq. mm conductor are solid Cl. 1 or stranded round Cl. 2 as per IS:8130. 10 Sq. mm conductor is stranded round or stranded compact conductor Cl. 2 as per IS 8130
Above 10 Sq. mm conductor are stranded round or compact round or compacted shaped Cl. 2 as per : IS 8130
Insulation : Crosslinked polyethylene (XLPE)
Core Color : Red, black
Inner Sheath : PVC/ PVC tape as per IS 7098 (P -1)
Outer Sheath : PVC Type ST - 2 as per IS 5831 (Option : FR Type/ FRLS Type)
Cable Color : Black (Options : Any other color as per requirement)

Cable Design Parameters

While ordering, in addition to the part number the following details shall also be advised:
Conductor Type (Aluminium or Copper) and class of conductor (class 1 or 2).
Sheath Type - PVC Type ST - 2 (FR or FRLS).



Part
Number
Nominal Cross -
Sectional Area
(Sq. mm)
Nominal
Thickness of
Insulation (mm)
Minimum
Thickness of
Inner Sheath
(mm)
Nominal
Thickness of
Outer Sheath
(mm)
Approx. Overall
Diameter
(mm)
Approx. Net Wt. of Cable (kg/km)
ALCable A2XY CU Cable 2XY
111400200004 4 0.7 0.3 1.8 13 180 235
111400200006 6 0.7 0.3 1.8 14 220 300
111400200010 10 0.7 0.3 1.8 17 280 400
111400200016 16 0.7 0.3 1.8 17 300 440
111400200025 25 0.9 0.3 2.0 19 340 650
111400200035 35 0.9 0.3 2.0 20 415 840
111400200050 50 1.0 0.3 2.0 22 520 1090
111400200070 70 1.1 0.3 2.0 25 680 1500
111400200095 95 1.1 0.4 2.2 28 880 2010
111400200120 120 1.2 0.4 2.2 31 1080 2500
111400200150 150 1.4 0.4 2.2 33 1295 3060
111400200185 185 1.6 0.5 2.4 37 1630 3840
111400200240 240 1.7 0.5 2.6 41 2070 4970
111400200300 300 1.8 0.6 2.8 44 2520 6160
111400200400 400 2.0 0.6 3.0 48 3200 7830
111400200500 500 2.2 0.7 3.4 54 4040 9990
111400200630 630 2.4 0.7 3.6 62 5130 12840
