Armoured Cable BS 5467

RR Kabel

Industrial wiring and mains distribution. Can be laid direct in the ground, or in ducts, clipped to surface

Application

Industrial wiring and mains distribution. Can be laid direct in the ground, or in ducts, clipped to surface, on trays or in free air. May be embedded in concrete.

Standard

BS 5467

Technical Data

Voltage Rating : 600/1000V
Minimum Bending Radius :15 x Cable diameter
Maximum Conductor Temperature : 90°C

Cable Construction

Single, two, three, four and five core cables. Stranded plain copper conductors, XLPE insulated, cores laid up, extruded PVC bedding, galvanised steel wire armoured (Aluminium wires for single cores) and PVC sheathed.

Core colours:
Single core : Brown or blue.
Two core : Brown, blue.
Three core : Brown, black, grey.
Four core : Brown, black, grey, blue.
Five code : Brown, black, grey, green/yellow, blue.
(There is the option for core colour as per customer requirement).
Sheath Colour : Black (Other colour as per customer requirement)

Note : Where a conductor operates at a temperature exceeding 70°C it shall be ascertained that the equipment connected to the conductor is suitable for the conductor operating temperature (see regulation 512-1-2 of BS 7671, the 17th Edition of IEE Wiring Regulations).
Cables with reduced Flame Propagation and designs with alternative core identification are available to order.
Cables up to 1 x 300 Sq. mm, 2...4 x 400 Sq. mm BASEC Certified.



Cable Design Parameters



Part Number

Nominal
Cross -
Sectional
Area
(Sq. mm)

Insulation
Thickness
(mm)

Armour Wire Diameter (mm)

Approx.
Dia. under
Armour
(mm)

Approx Overall Diameter (mm)

Approx Cable Weight (kg/km)

Maximum Resistance
of Cable

Reactance at 50 Hz (Ω/km)

Impedance AC at 90°C (Ω/km)

Star Capacitance (μf/km)

Maximum Armour Resistance  (Ω/km)

DC at 20°C (Ω/km)

AC at 90°C (Ω/km)

Single Core Aluminium Wire Armour

112600100050

50

1

0.9

12.7

17.5

800

0.387

0.4938

0.104

0.505

0.41

1.3

112600100070

70

1.1

1.25

14.7

20.2

960

0.268

0.341

0.101

0.356

0.46

0.75

112600100095

95

1.1

1.25

16.6

22.3

1240

0.193

0.2469

0.097

0.265

0.53

0.67

112600100120

120

1.2

1.25

18.5

24.2

1510

0.153

0.1962

0.094

0.217

0.56

0.61

112600100150

150

1.4

1.6

20.8

27.4

1900

0.124

0.1594

0.095

0.186

0.52

0.42

112600100185

185

1.6

1.6

23.2

30

2320

0.0991

0.128

0.093

0.158

0.54

0.38

112600100240

240

1.7

1.6

26

32.8

2930

0.0754

0.0985

0.09

0.134

0.59

0.34

112600100300

300

1.8

1.6

28.6

35.6

3580

0.0601

0.0797

0.088

0.119

0.63

0.31

112600100400

400

2.0

2

32.4

40.4

4600

0.047

0.0635

0.089

0.109

0.62

0.22

112600100500

500

2.2

2

36

44.2

5770

0.0366

0.0513

0.087

0.101

0.66

0.2

112600100630

630

2.4

2

40.4

48.8

7250

0.0283

0.0419

0.085

0.095

0.7

0.18

112600100800

800

2.6

2.5

45.6

55.4

9381

0.0221

0.0349

0.087

0.094

0.85

0.13

112600101000

1000

2.8

2.5

50.6

60.6

11540

0.0176

0.0303

0.085

0.09

0.87

0.12

Two Core Steel Wire Armour

112600200105

1.5

0.6

0.9

7.3

12.1

302

12.1

15.428

0.104

15.428

0.23

10.2

112600200205

2.5

0.7

0.9

8.5

13.6

346

7.41

9.448

0.101

9.449

0.25

8.8

112600200004

4

0.7

0.9

9.4

14.7

410

4.61

5.878

0.099

5.879

0.27

7.9

112600200006

6

0.7

0.9

10.5

15.9

499

3.08

3.927

0.094

3.928

0.3

7

112600200010

10

0.7

0.9

12.3

18

648

1.83

2.333

0.093

2.335

0.32

6

112600200016

16

0.7

1.25

14.3

20.4

978

1.15

1.466

0.088

1.469

0.35

3.7

112600200025

25

0.9

1.25

14.7

20.4

1290

0.727

0.926

0.082

0.93

0.38

3.7

112600200035

35

0.9

1.6

16.8

23.3

1500

0.524

0.6685

0.077

0.673

0.42

2.6

112600200050

50

1

1.6

19

25.8

1890

0.387

0.494

0.076

0.5

0.45

2.3

112600200070

70

1.1

1.6

22

29

2450

0.268

0.3412

0.075

0.349

0.49

2

112600200095

95

1.1

2

25.1

33.1

3300

0.193

0.2471

0.074

0.258

0.55

1.4

112600200120

120

1.2

2

27.9

36.1

4020

0.153

0.1964

0.072

0.209

0.57

1.3

112600200150

150

1.4

2

30.9

39.3

4750

0.124

0.1597

0.073

0.176

0.57

1,20

112600200185

185

1.6

2.5

34.9

44.7

6180

0.0991

0.1284

0.073

0.148

0.55

0.82

112600200240

240

1.7

2.5

39

49

7570

0.0754

0.0989

0.072

0.122

0.6

0.73

112600200300

300

1.8

2.5

43.3

53.5

9180

0.0601

0.0801

0.072

0.107

0.62

0.67

112600200400

400

2

2.5

48.4

59

10500

0.047

0.0641

0.071

0.096

0.64

0.59

Three Core Steel Wire Armour

12600301105

1.5

0.6

0.9

7.8

12.6

330

12.1

15.428

0.104

15.428

0.23

9.5

12600301205

2.5

0.7

0.9

9.2

14.1

390

7.41

9.448

0.101

9.449

0.25

8.2

12600300004

4

0.7

0.9

10

15.3

464

4.61

5.878

0.099

5.879

0.27

7.5

12600300006

6

0.7

0.9

11.2

16.6

568

3.08

3.927

0.094

3.928

0.3

6.7

112600300010

10

0.7

1.25

13.1

19.5

866

1.83

2.333

0.093

2.335

0.32

4

112600300016

16

0.7

1.25

15.3

21.6

1152

1.15

1.466

0.088

1.469

0.35

3.5

112600300025

25

0.9

1.6

18.9

25.5

1800

0.727

0.926

0.082

0.93

0.37

2.5

112600300035

35

0.9

1.6

21.3

28

2230

0.524

0.6685

0.077

0.673

0.42

2.3

112600300050

50

1

1.6

21.7

28.5

2490

0.387

0.494

0.076

0.5

0.45

2

112600300070

70

1.1

1.6

25.2

32.2

3290

0.268

0.3412

0.075

0.349

0.49

1.8

112600300095

95

1.1

2

28.8

37

4440

0.193

0.2471

0.074

0.258

0.55

1.3

112600300120

120

1.2

2

32

40.4

5470

0.153

0.1964

0.072

0.209

0.57

1.2

112600300150

150

1.4

2.5

35.9

45.5

6930

0.124

0.1597

0.073

0.176

0.55

0.78

112600300185

185

1.6

2.5

40

49.8

8350

0.0991

0.1284

0.073

0.148

0.55

0.71

112600300240

240

1.7

2.5

44.9

55.1

10400

0.0754

0.0989

0.072

0.122

0.6

0.63

112600300300

300

1.8

2.5

49.8

60.2

12600

0.0601

0.0801

0.072

0.107

0.62

0.58

112600300400

400

2

2.5

55.8

66.6

14600

0.047

0.0641

0.071

0.096

0.64

0.52

Four Core Steel Wire Armour

112600401105

1.5

0.6

0.9

8.5

13.5

365

12.1

15.428

0.104

15.428

0.23

8.8

112600401205

2.5

0.7

0.9

9.9

15

438

7.41

9.448

0.101

9.449

0.25

7.7

112600400004

4

0.7

0.9

11

16.4

532

4.61

5.878

0.099

5.879

0.27

6.8

112600400006

6

0.7

1.25

12.3

18.7

764

3.08

3.927

0.094

3.928

0.3

4.3

112600400010

10

0.7

1.25

14.5

21.1

1013

1.83

2.333

0.093

2.336

0.32

3.7

112600400016

16

0.7

1.25

17

22.9

1360

1.15

1.466

0.088

1.469

0.35

3.1

112600400025

25

0.9

1.6

21

27.6

2160

0.727

0.926

0.082

0.93

0.37

2.3

112600400035

35

0.9

1.6

23.6

30.4

2690

0.524

0.6685

0.077

0.673

0.42

2

112600400050

50

1

1.6

25

32

3130

0.387

0.494

0.076

0.5

0.45

1.8

112600400070

70

1.1

2

29.5

37.7

4500

0.268

0.3412

0.075

0.349

0.48

1.2

112600400095

95

1.1

2

33.3

41.7

5600

0.193

0.2471

0.074

0.258

0.55

1.1

112600400120

120

1.2

2.5

37.5

47.1

7400

0.153

0.1964

0.072

0.209

0.55

0.76

112600400150

150

1.4

2.5

41.6

51.4

8780

0.124

0.1597

0.073

0.176

0.55

0.68

112600400185

185

1.6

2.5

46.4

56.6

10630

0.0991

0.1284

0.073

0.148

0.55

0.61

112600400240

240

1.7

2.5

52.6

63

13390

0.0754

0.0989

0.072

0.122

0.58

0.54

112600400300

300

1.8

2.5

58

68.8

16290

0.0601

0.0801

0.072

0.107

0.62

0.49

112600400400

400

2

3.15

65.4

78.1

19800

0.047

0.0641

0.071

0.096

0.63

0.35

Five Core Steel Wire Armour

112600501105

1.5

0.6

0.9

9.7

14.3

410

12.1

15.428

0.104

15.428

0.23

8.2

112600501205

2.5

0.7

0.9

11.7

16.3

470

7.41

9.448

0.101

9.449

0.25

6.8

112600500004

4

0.7

0.9

13

17.8

710

4.61

5.878

0.099

5.879

0.27

6.2

112600500006

6

0.7

1.25

14.5

20

876

3.08

3.927

0.094

3.928

0.3

3.9

112600500010

10

0.7

1.25

17.2

22.9

1165

1.83

2.333

0.093

2.336

0.32

3.4

112600500016

16

0.7

1.6

20

26.6

1742

1.15

1.466

0.088

1.469

0.35

2.2

112600500025

25

0.9

1.6

24.7

31.5

2323

0.727

0.926

0.082

0.93

0.37

1.8

112600500035

35

0.9

1.6

27.8

34.8

2932

0.524

0.6685

0.077

0.673

0.42

1.6

112600500050

50

1

2

32.4

40.4

4192

0.387

0.494

0.076

0.5

0.45

1.1

112600500070

70

1.1

2

37.9

46.3

5336

0.268

0.3412

0.075

0.349

0.48

0.9



MULTICORE CONTROL CABLE STANDARD: BS 5467

Application

Industrial wiring for remote control and telemetry circuits etc. Can be laid direct in the ground, or in ducts, clipped to surface, on trays or in free air. May be embedded in concrete.

Technical Data

Voltage Rating : 600 / 1000V

Cable Construction

Multicore Cables : Stranded plain copper conductors, XLPE insulated, cores laid up, extruded PVC bedding, galvanised steel wire armoured and PVC sheathed
Core Colours : White with black numerals
Sheath Colour : Black. (Other Colour As per customer requirement) Minimum Bending Radius :12 x Cable Diameter
Maximum Conductor Temperature : 90°C
Note: Where a conductor operates at a temperature exceeding 70°C it shall be ascertained that the equipment connected to the conductor is suitable for the conduct or operating temperature (see regulation 512 -1 - 2 of BS 7671, the 17th Edition of IEE Wiring Regulations).
BASEC Certified up to and including 48 x 4 Sq. mm.

Cable Design Parameters

Part Number

Number of Cores

Nominal Cross - Sectional Area (Sq. mm)

Approx. Diameter Under Armour (mm)

Approx. Diameter Over Armour (mm)

Approx. Overall Diameter (mm)

Approx. Net Weight (kg/km)





112600701105

7

1.5

10.2

12.1

15.2

470



112600701205

7

2.5

12.3

14.1

17.1

600



112600700004

7

4

14

16.5

19.7

890



112601201105

12

1.5

13.7

16.2

19.4

780



112601201205

12

2.5

16.3

18.8

22.4

1000



112601200004

12

4

19.1

22.2

25.7

1410



112601901105

19

1.5

16.2

18.7

22.2

1000



112601901205

19

2.5

19.9

23.1

26.6

1540



112601900004

19

4

22.5

25.7

29.3

1830



112602701105

27

1.5

20

23.2

26.7

1500



112602701205

27

2.5

24

27.2

30.7

1950



112602700004

27

4

27.5

30.7

34.4

2500



112603701105

37

1.5

22.3

25.5

29

1800



112603701205

37

2.5

26.9

30.1

33.8

2350



112603700004

37

4

31

35

39.2

3100



112604801105

48

1.5

25.4

28.6

32.7

2050



112604801205

48

2.5

31

35

39.3

3100



112604800004

48

4

35.3

39.3

44.1

4100



Products By Category

GET IN TOUCH

Contact Us
