Application
To be used as ground conductor, un insulated hook up and jumpers.
Standards
IEC 60228, BS EN 60228, BS 6360
Description
Bare annealed copper, soft drawn.
Construction
The conductor consists of copper wires which are stranded together.
The construction of the conductor is according to the international standard of IEC 60220 / BS EN 60228 / BS 6360
Packing
In wooden drums
Table - Construction Details of Bare Soft Drawn Copper
Nominal Cross
Section
Sq. mm | No. of
strands | Approx
Strand diameter
mm | Approx
Conductor Diameter
mm | Max DC
Conductor Resistance
at 20°C | Approx net
Weight
Kg/Km |
| 16 |
7 |
1.68
|
5.0
|
1.15 |
139.0
|
| 25 |
7 |
2.13
|
6.4
|
0.727 |
224.0
|
| 35 |
7 |
2.52
|
7.6
|
0.524 |
314.0
|
| 50 |
19 |
1.78
|
8.9
|
0.387 |
427.0
|
| 70 |
19 |
2.14
|
10.7
|
0.268 |
617.0
|
| 95 |
19 |
2.52
|
12.2
|
0.193 |
856.0
|
| 120 |
37 |
2.04
|
14.2
|
0.153 |
1097.0
|
| 150 |
37 |
2.25
|
15.7
|
0.124 |
1335.0
|
| 185 |
37 |
2.47
|
17.1
|
0.0991 |
1610.0
|
| 240 |
61 |
2.23
|
19.5
|
0.0754 |
2162.0
|
| 300 |
61 |
2.47
|
22.0
|
0.0601 |
2652.0
|
