Conductor
Soft annealed electrolytic copper Cu-ETP according to DIN EN 13602, bare. Conductor construction according to ISO 6722 . (Concentric construction)
Insulation
Plasticized PVC with properties according to ISO 6722, Class B, lead free
Standards
DIN VDE 72 551 Part 5 & 6 ISO 6722
Temperature Rating
-40°C to +105°C
Properties
Concentric conductor (type A) and thin wall insulation
Dimensions
|
Nominal cross sectional area Sq. mm
|
No. of strands
|
Diameter of single wire Max. mm
|
Diameter of conductor Nom. mm
|
DC Conductor Resistance at 20°C Ω/km, Max.
|
Wall thickness mm. Nom.
|
Overall Diameter (Nom.)
|
|
Bare/Tinned Min.
|
Bare/Tinned Max.
|
|
0.22
|
7
|
0.21
|
0.7
|
77.9 /-
|
84.8/86.5
|
0.2
|
1.2
|
|
0.35
|
7
|
0.26
|
0.8
|
47.8 /-
|
52.0/54.5
|
0.2
|
1.3
|
|
0.5
|
19
|
0.19
|
1
|
34.1 /-
|
37.1/38.2
|
0.22
|
1.6
|
|
0.75
|
19
|
0.23
|
1.2
|
22.7 /-
|
24.7/25.4
|
0.24
|
1.9
|
|
1
|
19
|
0.26
|
1.35
|
17.0 /-
|
18.5/19.1
|
0.24
|
2.1
|
|
1.5
|
19
|
0.32
|
1.7
|
11.7/-
|
12.7/13.0
|
0.24
|
2.4
|
|
2
|
19
|
0.37
|
2
|
8.66 /-
|
9.42/9.69
|
0.28
|
2.8
|
|
2.5
|
19
|
0.41
|
2.2
|
7.0 /-
|
7.60 /7.80
|
0.28
|
3
|
