Feature
The cable has high flexibility subjected to light, ozone, oxygen, inert gas, and oil, and it is also resistant to the effects of cold heat, and fire. Suitable for use in open air, in dry as well as damp interiors. The high degree of flexibility does not form knots on the cable which could lead to Internal break of conductors.
Working Voltage U/U
450 V a.c. r.m.s.
Minimum Bending Radius
5 x cable diameter
Application
The Welding Cable is specially designed for the transmission of high currents from the electric welding machine to the welding tool. It is suitable for flexible use under rugged conditions, on assembly lines and conveyor systems, in machine tool and motor car manufacturing, shipbuilding, for welding machines.
Cable Construction
Superfine strands of bare Copper with single elastometric PVC insulation.
Test Voltage
3000 V
Outdoor Installation
Permanent
Temperature Range
0°C to +70°C
No.of Coresx Nominal
Cross Sectional
Area Sq.mm | Max.Strand
Diameter
(mm) | Max. CR (Spec)Ω/km | Nominal
Insulation Thickness
mm | Nominal
Cable Diameter
mm | Approx
Weight
kg/km |
| 10 |
0.31 |
1.91 |
2.0 |
8.2 |
140 |
| 16 |
0.31 |
1.21 |
2.0 |
9.2 |
200 |
| 25 |
0.31 |
0.78 |
2.0 |
10.5 |
285 |
| 35 |
0.31 |
0.554 |
2.0 |
11.5 |
375 |
| 50 |
0.31 |
0.386 |
2.2 |
13.6 |
540 |
| 70 |
0.31 |
0.272 |
2.4 |
15.6 |
740 |
| 95 |
0.31 |
0.206 |
2.6 |
18.0 |
1000 |
| 120 |
0.31 |
0.161 |
2.8 |
19.5 |
1230 |
| 150 |
0.31 |
0.129 |
3.0 |
21.3 |
1500 |
