Unarmoured Cable A2XY/2XY 3.5 Core

RR Kabel

1.1 kV, 3.5 Cores AL/ CU Conductor, XLPE Insulated, Unarmoured Cables as per IS:7098 Part-1

Cable Construction

1.1 kV, 3.5 Cores AL/ CU Conductor, XLPE Insulated, Unarmoured Cables as per IS:7098 Part-1.
Conductor : AL/ CU Stranded compact shaped conductor as per Cl. 2,15:8130
Insulation : Crosslinked polyethylene (XLPE)
Phase Core Color : Red, yellow, blue
Neutral Core Color : Black
Inner Sheath : PVC / PVC tape as per IS:7098 (P-1)
Outer Sheath : PVC Type ST-2 as per 15:5831 (Option: FR Type / FRLS Type)
Cable Color: Black (Options: Any other color as per requirement)

Cable Design Parameters

While ordering, in addition to the part number the following details shall also be advised:
Conductor Type (Aluminium or Copper) and class of conductor (Cl. 1 or 2).
Sheath Type - PVC Type ST-2 (FR or FRLS).

Part Number Size Cores x
Sq.mm + Neutral
(mm2)
Nominal Thickness
of Insulation
(mm)
Minimum Thickness
of Inner Sheath
(mm)
Nominal Thickness
of Outer Sheath
(mm)
Approx. Overall
Diameter
(mm)
Approx. Net Wt.
of Cable (kg/km)
AL Cable A2XY CU Cable2XY
111601010211 3 x 25 + 16 0.9/0.7 0.3 2.0 22 575 1125
111601020211 3 x 35 + 16 0.9/0.7 0.3 2.0 24 685 1425
111601030211 3 x 50 + 25 1.0/0.9 0.3 2.0 27 880 1980
111601040211 3 x 70 + 35 1.1/0.9 0.4 2.2 31 1185 2680
111601050211 3 x 95 + 50 1.1/1.0 0.4 2.2 34 1480 3580
111601060211 3 x 120 + 70 1.2/1.1 0.4 2.2 38 1880 4480
111601070211 3 x 150 + 70 1.4/1.1 0.5 2.4 43 2275 5485
111601080211 3 x 185 + 95 1.6/1.1 0.5 2.6 46 2770 6785
111601090211 3 x 240 + 120 1.7/1.2 0.6 2.8 52 3580 8675
111601100211 3 x 300 + 150 1.8/1.4 0.6 3.0 57 4380 10780
111601110211 3 x 400 + 185 2.0/1.6 0.7 3.4 65 5580 13980
111601120211 3 x 500 + 240 2.2/1.7 0.7 3.6 73 6980 17425
111601130211 3 x 630 + 300 2.4/1.8 0.7 4.0 82 8885 21970
